Street Lighting

Housing : Die cast aluminium.
Top Cover : Die cast aluminium.
LEDs : High power LEDs with high efficacy (>140lm/W), 3000K /4000K/5700K having Luminous Flux maintenance of 70% (L70 B20) at 50,000 Hrs.
Pole connection: Suited for poles with a diameter 60 mm.
Lens: High Efficiency PMMA Lenses, TYPE-1,TYPE-2,TYPE-3.
Diffuser: Clear Toughened Glass 4mm Thick, resistant to thermal shock.
Coating: Polyester resin powder coating, resistant to corrosion and saline environments.
Driver: Integral Driver with safety diode to protect the LED module against voltage peaks up to 4KV. P.F. > 0.95.
Ambient Temperature Zone : -30 ⁰C to +50⁰C
Input Voltage Range : 100V – 280V AC, 50-60 Hz

Housing : High Pressure die-cast aluminium with Cooling fins.
LEDs : Power LEDs with high efficacy (>135lm/W), having Luminous Flux maintenance of 70% (L70 B20) at 50,000 Hrs.
Pole connection: Suited for Pole brackets with outer diameter 60mm.
Lens: High Efficiency PMMA with Strada Optics – wide Angle 130° x 70°, TYPE-1,TYPE-2,TYPE-3.
Diffuser: Clear Toughened Glass 4mm Thick, resistant to thermal shock.
Coating: Polyester resin powder coating, resistant to corrosion and saline environments.
Driver: Integral Driver with safety diode to protect the LED module against voltage peaks up to 4KV. P.F. > 0.95.
Photometric performance: Multiple optical solutions through high photometric performance PMMA Lenses.
Ambient Temperature Zone : -30 ⁰C to +50⁰C
Input Voltage Range : 100V – 280V AC, 50-60 Hz

Housing : Die cast aluminium.
Top Cover : Die cast aluminium.
LEDs : High power LEDs with high efficacy (>140lm/W), 3000K/ 4000K/5700K having Luminous Flux maintenance of 70% (L70 B20) at 50,000 Hrs.
Pole connection: Suited for poles with a diameter 60 - 76mm.
Lens : High Efficiency PMMA Lenses. Type-III.
Coating: Polyester resin powder coating, resistant to corrosion and saline environments.
Diffuser: Clear Toughened Glass 4mm Thick, resistant to thermal shock.
Driver : Integral Driver with safety diode to protect the LED module against voltage peaks up to 4KV. P.F. > 0.95.
Ambient Temperature Zone : -30 ⁰C to +50⁰C
Input Voltage Range : 100V – 280V AC, 50-60 Hz

Housing : High Pressure die-cast aluminium with Cooling fins.
LEDs : Power LEDs with high efficacy (>130lm/W), having Luminous Flux maintenance of 70% (L70 B20) at 50,000 Hrs.
Pole connection: Suited for poles with a diameter 45 - 60mm.
Lens : High Efficiency PMMA with Strada Optics – wide Angle 130⁰ x 70⁰
Diffuser : Clear Polycarbonate V2 Self Extinguishing, UV Stabilized.
Coating: Polyester resin powder coating, resistant to corrosion and saline environments.
Driver Compartment : Integral IP 65. Driver with safety diode to protect the LED module against voltage peaks up to 4KV. P.F. > 0.95.
Ambient Temperature Zone : -30 ⁰C to +50⁰C
Input Voltage Range : 100V – 280V AC, 50-60 Hz
